1 SkyWire Quick Start Procedure Quick Start Guide AN213 Rev. 1.3 March, 2008 Radyne Corporation • 3138 E. Elwood St. •

AN213 - Rev. 1.3 Skywire Quick Start Guide 104.4 Terrestrial Interface Daisy chain, flow control, and quality of service are all accessible from

AN213 - Rev. 1.3 Skywire Quick Start Guide 115.0 SkyWire Network Configuration From the main menu, select Network Configuration and click on an

AN213 - Rev. 1.3 Skywire Quick Start Guide 12 Take note of the step size value listed in the Remotes panel. Enter settings for the dedicated IR a

AN213 - Rev. 1.3 Skywire Quick Start Guide 13 Figure 5-4 Configured Network – Remotes Created and Enabled

AN213 - Rev. 1.3 Skywire Quick Start Guide 14 Figure 5-5 Configured Network – Summary View

2SkyWire Quick Start Procedure AN213 - Record of Revisions Radyne Corporation is constantly improving its products and therefore the information

AN213 - Rev. 1.3 SkyWire Quick Start Guide 3 SkyWire Quick Start Procedure 1.0 Introduction The purpose of this document is to provide simple i

AN213 - Rev. 1.3 Skywire Quick Start Guide 4 Figure 3-2 Destination Configuration On the Login screen, specify the Read and Read/Write communit

AN213 - Rev. 1.3 Skywire Quick Start Guide 5The user gets to see which demodulators are installed and/or enabled. No remotes are active at this p

AN213 - Rev. 1.3 Skywire Quick Start Guide 64.1 Modulator Configuration To setup the modulator, simply enable the transmitter and select the car

AN213 - Rev. 1.3 Skywire Quick Start Guide 74.2 Demodulator Configuration There are up to four demodulators that may be installed in the SkyWire

AN213 - Rev. 1.3 Skywire Quick Start Guide 84.3 BUC and LNB Configuration To setup the BUC and/or LNB, select the corresponding tab on the satel

AN213 - Rev. 1.3 Skywire Quick Start Guide 9 Figure 4-6 LNB Tab Edit Mode
